High-Quality Pellet Dies for Feed Pellet Mills With High-Wear Resistance
Our ring die is a crucial component designed specifically for feed pellet machines. It is meticulously crafted with advanced manufacturing techniques and premium materials to ensure outstanding performance and durability.
Made from high-grade alloy steel, this ring die exhibits excellent wear resistance, allowing it to withstand the continuous abrasion caused by the raw materials during the pelleting process. The precise holes drilled on its surface are uniformly distributed, guaranteeing the production of pellets with consistent size and shape. This not only enhances the quality of the feed pellets but also optimizes the efficiency of the pelletizing operation.
The innovative design of our ring die features a smooth inner wall and proper chamfering at the edges of the holes, which effectively reduces material blockage and facilitates the smooth extrusion of pellets. Additionally, it undergoes a series of strict heat treatment processes to further improve its hardness and toughness, making it suitable for long-term, high-intensity use in various feed production environments.
With our reliable ring die, you can expect increased productivity, reduced downtime due to component failure, and ultimately, greater profitability in your feed manufacturing business. It is truly an investment that pays off in the long run.
Shanbao Machinery's Pellet Die Application
We have produced many pellet dies for some famous pellet mills, like: CPM, Buhler, Van Aarsen, Andritz, Idah, Matador, PTN, Muyang, SZLH, Famsun,...
| CPM | CPM305 | Buhler | Buhler 35 | MUZL | MUZL 1200 |
| CPM407 | Buhler 40 | MUZL 1210C |
| CPM3016-4 | Buhler 42 | MUZL 1610/C |
| CPM3016-5 | Buhler 42B | MUZL 35 |
| CPM3020-6 | Buhler 508 | MUZL 42 |
| CPM3020-6 | Buhler 508E | MUZL 42T |
| CPM3022-6 | Buhler 52 | MUZL 460 |
| CPM3022-8 | Buhler 530 | MUZL 550 |
| CPM7726-7 | Buhler 660 | MUZL 600 |
| CPM7726-9 | Buhler 900 | MUZL 600TA |
| CPM7730-8 | | MUZL 610 |
| CPM7730-10 | | MUZL 610TW |
| CPM7936-14 | | |
| Application | Hole Diameter | Compression Ratio |
| Poultry & Livestock | 2.5-4mm | 1:4-1:16 |
| Fish Feed | 2.0-5.0mm | 1:12-1:14 |
| Shrimp Feed | 0.8-2.0mm | 1:18-1:30 |
| Crab Feed | 4.5-10.0mm | 1:15-1:26 |
| Biomass and Fertilizer | 6.0-8.0mm | 1:4.5-1:8 |
YOU WILL GET MORE TO COLLABORATE WITH SHANBAO MACHINERY!
Product Tags:
|
|
Feed Pellet Mills Pellet Dies with Ra 0.4-1.2 Hole Finish and HRC 52-55 Hardness Images
|
